High Tensile Lifting Rings G80 – Vòng Nâng Tải Trọng Cao G80

G80 hoist swivel eye  is most commonly used for lifting and load restraint applications. There are different options with different sizes and capacities from M8-M100 (0.6-50 Tons). Adjustable in different direction of pull.  A plane bolting surface guaranteed. The material to which the lifting point is attached should be adequate strength to withstand forces during lifting without deformation. With captive screw.

Equipped with ball bearing, 360°rotation.
Can be loaded in all directions with a safety factor of 4 times;
Oblong ring manufactured according to DIN1677-4 grade 80;

1. grade:G80
2.Material:alloy steel
3.Process:drop forged
4.Surface:powder coated
5.W.l.l:0.6-50t
6.Usage:lifting
7.Size:8mm-100mm

Fatigue Rated x 1.5 WLL for 20,000 cycles
Proof Tested – 2.5 times Working Load Limit
100% Magnaflux Crack Detected
Super Alloy Steel
Grade 80

Highly efficient operation
Excellent tensile strength
Good protection against breakage in all directions

This product has a rated WLL but is subject to the correct welding procedure being carried out by a suitably qualified welder.

This Lifting Point is ideally suitable for lifting and lashing applications such as excavators, low loaders, lifting beams etc…..

Widely used on farm machinery, trucks, steel hulled marine vessels nd material handling equipment.
